The only thing I can offer Oding is that most cars now sit on coil springs and most lorries on air bags so I would guess it's a dying art.

A quick search on YouTube brings up a few videos including this one in the states.



[oding]



[oding]

Had to share this lovely front.



[oding]

The only thing I can offer Oding is that most cars now sit on coil springs and most lorries on air bags so I would guess it's a dying art.

A quick search on YouTube brings up a few videos including this one in the states.

I agree with you StarCruiser, it is a dying trade. I plan to do it myself.



[StarCruiser]

I agree with you StarCruiser, it is a dying trade. I plan to do it myself.

That doesn't surprise me Oding, I kind of thought that when I posted the vid. Doing it yourself I mean.



[clivehorridge]

That doesn't surprise me Oding, I kind of thought that when I posted the vid.

Nothing beats a hands on approach.

My limited experience with leaf springs, reminds me that one set had little hard-wood 'packs' between the top leaf and the second row. They were worn/missing, so I made some from oak, and it took a lot of the harshness out of the spring, and lifted it a little.

I don't know how many leaves the 60 springs have, but IIRC, it's only the top 2 that govern ride-height, the others simply support them under heavier loads.



[oding]

Nothing beats a hands on approach.

My limited experience with leaf springs, reminds me that one set had little hard-wood 'packs' between the top leaf and the second row. They were worn/missing, so I made some from oak, and it took a lot of the harshness out of the spring, and lifted it a little.

I don't know how many leaves the 60 springs have, but IIRC, it's only the top 2 that govern ride-height, the others simply support them under heavier loads.

About what you shared regarding the piece of wood. I think that would work. Thickness and length of that wood will be a trial and error. Thank you.



[clivehorridge]

About what you shared regarding the piece of wood. I think that would work. Thickness and length of that wood will be a trial and error. Thank you.

IIRC Oding, the springs I was talking about had a depression in the underside of the top leaf, about 7 cm short of the overlap with the second leaf, measured from the centre of the leaves.

It was very slight, maybe only 2mm, and circular, just enough to retain a carefully profiled disc of hardwood. It seemed very odd to me at the time for them to have used wood, and I suppose these days a polypropylene or similar would be used.

Just thought I'd mention it.



[StarCruiser]

IIRC Oding, the springs I was talking about had a depression in the underside of the top leaf, about 7 cm short of the overlap with the second leaf, measured from the centre of the leaves.

It was very slight, maybe only 2mm, and circular, just enough to retain a carefully profiled disc of hardwood. It seemed very odd to me at the I suppose these days a polypropylene or similar would be used.

Just thought I'd mention it.

I've seen what you mean Clive. My Mk1 Shogun was on leaf springs at the back and had plastic pads snapped into punched oval holes in the springs to locate them towards the end of an otherwise flat strip. They were very thin, perhaps 2mm and I always thought they were there as bearing surfaces to stop the leaves squeaking.



[clivehorridge]

I've seen what you mean Clive. My Mk1 Shogun was on leaf springs at the back and had plastic pads snapped into punched oval holes in the springs to locate them towards the end of an otherwise flat strip. They were very thin, perhaps 2mm and I always thought they were there as bearing surfaces to stop the leaves squeaking.

That's reassuring, I stared to wonder if I'd dreamed it Rich!

For sure, after replacing mine, the ride was much smoother, but I'd greased them as well so it was a combined effect. The lift gained was about 1/2 inch (10-12mm) IIRC.
